Crawler 1/10 Pro Brushless 4107 (Patrol) Gray RTR Yikong

Inclui:

Crawler 1:10 Pro Brushless 4107 (Patrol) Cinza RTR Yikong

Necessita:

Bateria  2S 7.4V ou 3S 11.1V
Carregador de baterias

Informação adicional da marca:

The YK4107 PRO is Yikongs latest 1/10 crawler model. With advanced engineering including a newly optimized LCG chassis design, durable components, and true brushless power, this crawler delivers real off-road performance! Thanks to its portal axles, patented DIG function (which locks a single rear wheel for a tighter turning radius), and 2-speed transmission, its perfect for demanding climbing tracks and off-road enthusiasts who value realism and performance.

Features

• 1:10 4WD crawler with portal axles and Tank Turn / DIG function
• Brushless outrunner motor (2100KV) with 60A ESC
• 2-speed transmission (High/Low) switchable via transmitter
• All-metal gear system, CVD driveshafts, full ball bearings
• Hydraulic oil-filled shock absorbers, fully adjustable
• 25kg digital metal-gear servo with built-in damping
• LED lighting system (front & rear) switchable via transmitter
• Polycarbonate body with simulated interior detail
• Optimized Low-Center-of-Gravity (LCG) chassis design
• 2.4GHz 10-channel radio system with Climb/Race mode

Technical Specifications

Scope of delivery

Pre-assembled RC crawler (RTR, without battery & charger), 10-channel transmitter, user manual.

YIKONG YK4107Pro 1/10 RC Crawler
What are the main new features of YIKONG YK4107 Pro?

1. Adopting the new LCG chassis;
2. Tank U-turn function to meet special climbing requirements;
3. 25KG high-torque servo metal gear, improved servo buffer protection device.
4. Climbing mode and competition mode.
5. 2100KV Brushless Motor.
6. 60A Brushless Electronic Speed Controller (ESC)
Note: This link does not include batteries and chargers.

You need to purchase batteries and chargers separately.

About the package of YK4107 Pro RC Car:

1X RC Car body (Complete kit, but, not including the battery and charger.)

I. Overview

• Brand: YIKONG
• Model: YK4107 Pro
• Name: 1:10 Scale Remote – control Start Tank – turn Crawler
• Dimensions: 521mm * 247mm * 267mm
• Weight: 3.1kg
• Colors: Emerald-green (currently the first batch of goods only this color, other colors are coming)
• Shell: the material enhances the metal grain texture.

II. Specifications

• Wheelbase: 325mm
• Track Width: 267mm
• Approach Angle: 58°
• Departure Angle: 52°
• Steering Angle: 40°
• Ground Clearance: 65mm
• Tire Diameter/Width: 116/42mm

III. Features of YIKONG YK4107 Pro RC Crawler

(1) High – performance Servo

A 25KG high – torque metal – gear steering servo with a newly – designed servo buffer protection device.

(2) Ultra – low Center of Gravity Gearbox Design

(3) Tank – turn Function

Press the Channel 4 button to activate the tank mode, and the rear differential lock will open automatically to achieve the tank – turn.

(4) Optional Parts

Optional front and rear counterweight blocks for weight adjustment.

(5) Professional Configuration

Remote – control System:

A 2.4GHZ 10CH transmitter with optional driving modes.

Remote – control front and rear differential locks, two – speed ratio (two – in – one electronic speed controller, high – low speed switching).

Other Components:

Full – metal hydraulic shock absorbers with remote – control lighting system for the whole vehicle.

Professional – level climbing tires, a 2100KV Brushless Outrunner Motor, full – metal gears and ball bearings, front and rear portal axle design, front universal joint.

The towing force is adjustable via the remote – control switch, with simulated interior, 1.2mm PC car body (transparent windows).

60A Brushless Electronic Speed Controller (ESC)

The front bumper is replaceable.

IV. Gear Ratio Parameters

The low – speed and high – speed gear ratios corresponding to different motor gears are listed (see the table for details).
